Panzhihua Iron and steel, China Mobile and Huawei jointly selected gsma2022 5g industry application cases in China

2022-05-05

Panzhihua Iron and steel, China Mobile and Huawei jointly selected gsma2022 5g industry application cases in China


In the first quarter of 2022, the "Pangang mining 5g long-distance mining" project jointly built by Pangang Group, China Mobile, Huawei, BirA technology and other partners in Zhulan iron mine, Panzhihua, Sichuan was selected into GSMA "2022 China 5g vertical industry application case". GSMA is a global industry organization in the field of mobile communication established in 1987 and the organizer of the world mobile communication conference. Its annual "Pakistan Exhibition" held in Barcelona is widely known as the "Oscar" in the field of ICT. "We have selected three fields of 5g City, intelligent manufacturing and intelligent mine as the breakthrough point of 5gtob scale... And selected excellent application cases to promote and promote large-scale replication all over the world, so as to realize the transformation from informatization and automation to digitization and intelligence in relevant fields." Said Si Han, President of GSMA Greater China.


Smart mine


The "5g long-distance mining" project of Pangang mining is a 5g + smart mine solution tailored for Zhulan iron mine of Pangang mining by China Mobile, Huawei, Berra and Chuangyuan. Based on the current situation of perforation, mining and transportation management in Panzhihua Iron Mine open pit, focusing on the core construction objectives of intrinsic safety, cost reduction and efficiency increase, aiming at the three core scenarios of mine card driverless, shovel remote control and rig remote control in the working face, with the support of China Mobile, Huawei 5g and edge computing technology, the high-definition video uplink in remote control and driverless of working equipment in the open pit face is solved, with large bandwidth, low delay of control instructions In order to realize the automatic driving of mining dump truck and the remote control function of mining truck and electric shovel. Li Yibing, general manager of the enterprise management department of Pangang Mining Co., Ltd., introduced that "digital transformation is the only way for the future development of Pangang, especially the mining company. The project is an important part of the company's mine digital and intelligent transformation... The project allows our workers to work with more dignity in a more comfortable working environment, in a better position."


Smart mine


Panxi area of Sichuan Province is one of the areas with the most abundant mineral resources in China and even the world. It is the second largest iron ore area in China. It contains more than 10 billion tons of vanadium titanium magnetite resources, with high comprehensive utilization value. For a long time, the mining operation area under Panzhihua Iron and Steel Group Mining Co., Ltd. has some difficulties, such as poor working environment and extremely difficult conditions. The mining workers can only return to the urban area on weekends, and young people are unwilling to work in the mining area. At present, the mining and transportation process flow of open-pit mines mainly includes perforation, blasting, shovel loading, transportation and other links. The mining and transportation operation mainly depends on workers driving drilling rigs, electric shovels, mine cards and other mobile equipment to complete the operation. Due to the harsh working environment (high temperature, dust, etc.), the labor intensity of mining face personnel is high, the work risk is high, and it is difficult to recruit workers for mining and transportation operation. At the same time, the use of equipment depends on the experience of workers, The comprehensive utilization efficiency of equipment is also relatively low. In view of these situations, in recent years, although some transportation work of mining face operation has been solved through socialization, on the one hand, experienced workers are still required to operate high-value drilling rigs, electric shovels and other equipment on the site. On the other hand, socialization only temporarily transfers the problems, and does not fundamentally solve the safety of mining and transportation work, the "aging" of employees and the difficulty of recruitment, Therefore, the mine urgently needs new solutions.


Smart mine


Remote control includes the remote control system of mine card and electric shovel. Collect real-time position information, status information and video information of mining card and electric shovel, and provide control, monitoring, early warning, task scheduling and other functions. On the one hand, the system realizes the access and monitoring of mining card and electric shovel equipment based on the central control system, on the other hand, it provides the remote control cabin of relevant equipment to realize the remote real-time operation of various equipment. The remote control center is equipped with a remote cockpit. Receive real-time data of all equipment through remote control and auto drive system, store, analyze and visualize information, provide human-computer interaction interface, and provide equipment remote control and automatic mining task issuing capability.


Smart mine

BirA technology's remote control center in Zhulan iron mine of Panzhihua Iron and Steel Co

The operator can inspect the mining site from the sofa chair

Monitoring, scheduling and manual intervention in emergencies


On the current basis, the production and application promotion of 3 drills, 3 shovels and 6 trucks in Panzhihua Iron Mine will be realized successively, and the scene pilot will be carried out in Baima iron mine; In 2023, Panzhihua Iron Mine will be fully covered (16 drilling rigs, 23 electric shovels and 27 ore cards), and production, application and promotion will be carried out in Baima iron mine; In 2024, the whole Baima iron mine will be covered; According to the design progress of honggenan mine, relevant scene practice standards are integrated into the design.
